Hot Bottom
The Hot Bottom models are steam heated evaporators. The steam chamber is an A.S.M.E. “U” stamped pressure vessel rated to 150 psi. Steam is supplied by a plant boiler, steam generator, or a packaged boiler system dedicated for evaporation.
Steam is the energy of choice where possible as it offers unparallel energy versatility, efficiency, and economy. The efficient heat transfer and relatively low temperature of steam is ideal for evaporation of wastewater because of the reduction of solids sticking to the heating surface.
Hot Tube, Hot Shot, and Hot Bottom are registered trademarks of Lakeview Engineered Products, Inc. Lakeview Engineered Products reserves the right to make product specification changes and/or updates to their wastewater evaporators without prior notice.
| Hot Bottom |
evaporation rate |
tank dimensions |
tank capacity |
weight | ||||
| model | gph | steam/hr | L | W | H | max | nom | lbs |
| E-200 | 25 | 250# | 71" | 50" | 71" | 230 | 180 | 1400 |
| E-300 | 32 | 320# | 86" | 50" | 71" | 300 | 240 | 1800 |
| E-600 | 65 | 650# | 113" | 65" | 75" | 750 | 650 | 2400 |
| E-750 | 96 | 1000# | 161" | 66" | 75" | 1150 | 1000 | 3450 |
| E-900 H/O | 200 | 2150# | 208" | 65" | 74" | 1590 | 1300 | 4250 |
| E-1200 H/O | 250 | 2750# | 257" | 64" | 74" | 1885 | 1600 | 7700 |
